RESEARCH ARTICLE


Long-Term Visual, Refractive and Topographic Outcomes of KeraRings Combined with Accelerated Transepithelial Crosslinking for Management of Different Grades of Progressive Keratoconus: A Retrospective Cohort Study



Mohammed Iqbal1
iD
, Amr Mounir1, *
iD
, Khaled Abd-Elaziz2, Omar M. Said3
iD

1 Department of Ophthalmology, Faculty of Medicine, Sohag University, Sohag, Egypt
2 Department of Ophthalmology, Faculty of Medicine, Beni Suef University, Beni Suef, Egypt
3 Department of Ophthalmology, Faculty of Medicine, Fayoum University, Fayoum, Egypt


© 2021 Iqbal et al.

open-access license: This is an open access article distributed under the terms of the Creative Commons Attribution 4.0 International Public License (CC-BY 4.0), a copy of which is available at: https://creativecommons.org/licenses/by/4.0/legalcode. This license permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.

* Address correspondence to this author at Department of Ophthalmology, Faculty of Medicine, Sohag University, Sohag, 82425, Egypt; Tel: +2 01005026170; E-mail: dramrmonir@yahoo.com


Abstract

Purpose:

To evaluate long-term visual, refractive, and topographic outcomes of KeraRings intrastromal implantation combined with accelerated transepithelial cross-linking for management of different stages of progressive keratoconus.

Materials and Methods:

This retrospective cohort study included 70 eyes of 70 patients with Amsler-Krumeich grades 1 to 4 keratoconus. They were divided into two groups: group-A included 37 eyes with grades 1-2 keratoconus, and group-B included 33 eyes with grades 3-4 keratoconus. Both groups underwent combined Keraring implantation with TCXL treatment. The main outcome measures included the preoperative and postoperative visual acuity, refraction, keratometry readings, and pachymetry.

Results:

At postoperative month 60, group-B exhibited significantly higher values of all mean uncorrected distance visual acuity (UDVA), corrected distance visual acuity (CDVA), sphere/cylinder/spherical equivalent/defocus equivalent (DEQ), and K1/K2/Kaverages/Kmax parameters compared to that of group A. However, group-A exhibited better stability of postoperative improvements. Keratoconus progression (KCP) was greater in group-B (45.5%) than group-A (10.8%). Two eyes revealed segments' migration while one eye showed tunnel vascularization and opacification with segments' migration.

Conclusion:

The diagnostic criteria of preoperative-KCP are not adequate for the diagnosis of postoperative-KCP following ICRS implantation. UDVA and K average posterior seemed to be more sensitive parameters than K max in documenting early postoperative-KCP. We suggest that deterioration of UDVA≥0.10 log MAR and/or K average posterior ≥0.25 D are highly suspicious of post-ring implantation keratoconus progression (PR-KCP). The occurrence of two of the following parameters: Kmax≥0.50 D, Kaverageanterior≥0.50 D, K average posterior ≥0.25 D, or pachymetry≥1.5% thinning, is diagnostic of PR-KCP. The occurrence of two or more of the following parameters: Kmax≥0.50 D, Kaverageanterior≥0.50 D, Kaverageposterior ≥0.25 D, pachymetry≥ 1.5% thinning or UDVA≥0.10 logMAR, is diagnostic of PR-KCP. We also suggest that Kmax≥0.75 D alone is diagnostic of PR-KCP.

Key Words: Keratoconus, Intracorneal rings, Kerarings, Corneal cross-linking, Progression, Stability, Topographic outcomes.



1. INTRODUCTION

Keratoconus (KC) is a bilateral progressive asymmetrical ectatic disease of the cornea with multifactorial etiological factors lead to stromal thinning and corneal protrusion [1]. Vernal keratoconjunctivitis [2], chronic eye rubbing [3], thyroid disease [4, 5], pregnancy, and lactation [6] are known risk factors that could promote keratoconus progression (KCP) [7, 8].

The first known effective treatment that halts KCP is the corneal collagen standard cross-linking (SCXL) that was introduced by Wollensak et al. in 2003 [9]. Accelerated epithe- lium-off CXL (ACXL) and accelerated epithelium-on, also known as transepithelial CXL (TCXL), are the two major modifications aimed to achieve the previously mentioned objectives [10-15]. However, several other studies proved the superiority of SCXL versus both ACXL and TCXL in adult and pediatric KC patients [16-23].

Intracorneal ring segments (ICRS) are introduced as a refractive device that helps to support the cone, flatten the corneal surface, and improve the spherical and astigmatic status, thus improving the patients’ visual acuity and quality [24, 25]. The ICRS advantages, disadvantages, timing, indications, evolving nomograms, and their ability to stabilize the ectatic cornea, thus preventing KCP, are still being debated [26, 27]. Meanwhile, combination procedures known as cross-linking plus (CXL-Plus) have become popular among corneal surgeons [28-35]. Keraring segments (Mediphacos Inc., Belo Horizonte, Brazil) are common ring segments that are used as corneal implants worldwide [35, 37].

Over the last decade, several studies recommended the use of Kmax as the main parameter besides other parameters for documentation of KCP, i.e., KCP is documented when Kmax≥1 D [38-42]. However, in 2015, based on the global consensus on keratoconus and ectatic diseases, the panel defined keratoconus progression as the occurrence of 2 of the 3 identified parameters of KCP, which causes an increase in the steepening of the anterior corneal curvature, the posterior corneal curvature, and the corneal thinning [43]. Belin ABCD progression display and the Belin-Ambrosio Enhanced Ectasia Display (BAD) are recently introduced as new accurate topographic tools for screening and documenting KC progression [44-47].

The primary aim of this study was to compare the effectiveness of Keraring segments implantation combined with TCXL in low-grade (grades 1 and 2 Amsler-Krumeich) versus high-grade keratoconus (grades 3 and 4 Amsler-Krumeich). The secondary aim was to evaluate the long-term stability in both groups with the demonstration of the prognostic and diagnostic parameters of post-ring implantation keratoconus progression (PR-KCP).

2. METHODS

2.1. Study Design

This retrospective cohort study is approved by the Institutional Review Board of the Sohag Faculty of Medicine, Sohag University, Egypt, and adhered to the tenets of the Declaration of Helsinki. All surgeries were performed in private eye centres in Sohag city (Future Femtolaser Center) and Giza city (Rowad Correction Center), Egypt.

This study included 70 eyes of 70 KC patients. The nature of the disease, its manifestations, treatment plans, and potential sequelae were properly explained in detail to all patients who signed informed consent before surgery. We obtained the preoperative and postoperative data from the patients’ medical files.

Inclusion criteria are as follows: documented KC progression (Kmax>1 D); grades 1, 2, 3 or 4 keratoconus (Kaverageanterior [mean keratometry on anterior corneal surface] value <48 D, 48–53 D, >53-55 D and >55 D, respectively) based on the Amsler-Krumeich classification (AK). On the other hand, our exclusion criteria are as follows: <46 D Kaverageanterior; <350 μm corneal thickness at the thinnest location (CTT); previous or concomitant eye rubbing; vernal keratoconjunctivitis (VKC); ocular surgery; opacities; or dry eye disease.

All eyes were subjected to preoperative and postoperative assessments of visual acuity, subjective refraction, slit-lamp and fundus examinations, and corneal topography. Our primary outcome measures are as follows: UDVA; CDVA; subjective refractive sphere, cylinder and Spherical Equivalent (SE); defocus equivalent (DEQ) pachymetry (CTT), keratometry (K readings) including K1, K2, Kaverageanterior, and Kmax on the anterior corneal surface and Kaverageposterior on the posterior corneal surface. Our secondary outcome measures were to discover the most reliable parameters and measure their values to document PR-KCP.

2.2. Grouping of Study Participants

The eyes were divided into one of two groups. Patients in each group were subjected to TCXL combined with Keraring implantation. Group A included eyes with AK grades 1 and 2 keratoconus that represented the low-grade keratoconus group. Group B included eyes with AK grades 3 and 4 keratoconus represented the high-grade keratoconus group.

In addition, we planned to conduct additional subgroup analyses of the entire 70 eyes. Therefore, the 70 eyes were also subdivided into 3 subgroups according to their final postoperative status at postoperative 60 months. The first subgroup was the stability subgroup (S-subgroup), which included eyes with almost stable postoperative visual, refractive and topographic outcomes during 60 months follow-up period. The second subgroup was the improvement subgroup (I-subgroup), which included eyes with regression and improved postoperative visual, refractive and topographic outcomes during 60 months follow-up period. The third subgroup was the progression subgroup (P-subgroup), which included eyes with progression and deteriorated postoperative visual, refractive and topographic outcomes during 60 months follow-up period. Postoperative KCP was documented when Kmax exceeded 1 D. Comparisons were made between groups and subgroups to document their effectiveness and related stability.

The devices used in this study are as follows: CSO SIRIUS Topographer (CSO, Florence, Italy), the iFS advanced femtosecond laser (Abbott Laboratories Inc., Abbott Park, IL, USA), the KXL System (Avedro Inc., Burlington, MA, USA). All Keraring segments (SI-5 model, a triangular cross-sectional design with a 5 mm optical zone) were chosen based on the manufacturer’s standard nomogram (Keraring Calculation Guidelines 2009, version 5.2; Mediphacos Inc.), which determined the number, thickness, and arc-length of implanted Keraring segments.

2.3. Surgical Procedure

The corneal tunnel creation parameters were inner diameter 5.00 mm, outer diameter 5.90 mm, entry cut length 1.40 mm, and entry cut thickness 1 mm. The depth of the tunnel was 80% of thinnest corneal thickness, provided that at least 100 µm existed between the tunnel and the corneal endothelium. The site of the incision was created at the steepest axis.

Topical 0.4% benoxinate hydrochloride anesthetic eye drops (BENOX Sterile Ophthalmic Solution, EIPICO, Tenth of Ramadan City, Egypt) were instilled 3 times with 5 minutes intervals. All patients were instructed to look at the flashing light to mark the corneal centre accurately. The eye was fixated by a suction ring during the iFS tunnelling of the cornea. Then, the patency of the tunnel was checked by using a spatula. Thereafter, we implanted one or two Keraring segments as determined by the standard nomogram.

2.3.1. Transepithelial CXL

The next step was to perform TCXL. We instilled 0.25% riboflavin solution supplemented with BAC, EDTA, trometamol, hydroxypropyl-methylcellulose (ParaCell, Avedro) onto the corneal surface every 1.5 minutes for 4.50 minutes soaking time. Thereafter, we instilled 0.25% riboflavin solution (VibeX Extra, Avedro) every 1.5 minutes for 6 minutes soaking time. The surgeon had checked the stroma riboflavin loading after instillation by slit-lamp examination. TCXL parameters are as follows: 45 mW/cm2 power, 7.2 J/cm2 energy, pulsed mode (one second on and one second off), 2.40 minutes UV treatment time, and 5.20 total treatment time.

2.3.2. Postoperative Treatment and Follow-up

The postoperative topical treatment are as follows: prednisolone acetate 1% eye drops (Pred Forte, Allergan, Inc, Jersey City, USA), gatifloxacin 0.3% eye drops (Zymar, Allergan, Inc, Jersey City, USA), and sodium hyaluronate 0.15% eye drops (Hyabak, THEA laboratories, Clermont-Ferrand, France). The eye drops were instilled 4 times daily for the first 5 days and twice daily for the next 10 days. At the first postoperative follow-up visit, we removed the bandage contact lenses. The postoperative follow-up visits were scheduled at postoperative day 1, week 1, as well as months 1, 6, 12 then annually. However, corneal topography was, unfortunately, available for all eyes only at postoperative first, fourth, and fifth years.

2.4. Statistical Analysis

Data were analyzed using STATA version 14.2 (Stata Statistical Software: Release 14.2 College Station, TX: StataCorp LP.). Quantitative data were represented as mean, standard deviation, median, and range. Data were analyzed using student t-test to compare means of two groups and ANOVA for comparison of the means of three groups or more. When the data were not normally distributed, the Kruskal Wallis test for comparison of three or more groups and Mann-Whitney test was used to compare two groups. Qualitative data were presented as numbers and percentages and compared using either the Chi-square test or Fisher exact test. A comparison was made between preoperative and postoperative follow-up data at 12, 48, and 60 months using the RM ANOVA test. Sphericity was examined using Mauchly's Test of Sphericity. Bonferroni post hoc test was used to examine the difference at each time point. P-value was considered significant if it was less than 0.05.

3. RESULTS

This study included 70 eyes of 70 keratoconus patients (51% male, 49% female). The mean age of patients in group A (n=37) was 26.35±5.83 years, and in group B (n=33) was 28.55±6.06 years. Table 1 shows the characteristics of the studied patients and their eyes descriptive statistics. We recorded no statistically significant differences between both groups regarding these values; however, there were significant differences between S, I, and P subgroups (p=0.004).

Table 1. Patient characteristics.
Variable Group A
N=37 eyes of 37 patients
Group B
N=33 eyes of 33 patients
P-value
Age/years
Mean ± SD
Median (range)
26.35±5.83
28 (15:36)
28.55±6.06
29 (16:45)
0.12
Gender
Total Patients (70)
Males (36)
Females (34)
37
17 (55%)
20 (45%)
33
19 (58%)
14 (42%)
0.39
Preoperative KC grading
Eyes (70)
A1 (Grade 1, mean K <48 D)
A2 (Grade 2, mean K 48-53 D)
A3 (Grade 3, mean K 53-55 D)
A4 (Grade 4, mean K >55D)
37
8 (22%)
29 (78%)
-
-
33
-
-
16 (48%)
17 (52%)
0.39
Postoperative subgrouping:
Stability subgroup (S-subgroup)
Improvement subgroup (I-subgroup)
Progression subgroup (P-subgroup)
24 (65%)
9 (24%)
4 (11%)
11 (33%)
7 (21%)
15 (46%)
0.004
Table 2. Visual, refractive, and topographic data analysis of the studied eyes (n=70).
Parameters Preoperative
Mean ± SD
Median (Range)
Postoperative
12th month
Mean ± SD
Median (Range)
Postoperative
48th month
Mean ± SD
Median (Range)
Postoperative
60th month
Mean ± SD
Median (Range)
Difference (post-60m-pre)
Mean ± SD
(95% CI)
P-value
UDVA 1.21±0.28
1.2 (0.7:1.7)
0.49±0.20
0.5 (0.1:1.0)
0.54±0.23
0.5 (0.1:1.1)
0.63±0.29
0.6 (0.2:1.4)
-0.59±0.28
(1.14:1.28)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.004,P5<0.0001,P6<0.0001
CDVA 0.46±0.19
0.5 (0:0.9)
0.19±0.11
0.2 (0:0.7)
0.18±0.11
0.2 (0:0.6)
0.19±0.12
0.2 (0:0.6)
-0.27±0.12
(-0.30:-0.24)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.004, P5=0.90,P6=0.05
Sphere -6.46±3.02
-5.5 (-13.25:-1.5)
-2.92±2.06
-2.88 (-7.75:0.25)
-3.13±2.10
-2.75 (-7.5:0)
-3.26±2.17
-2.88 (-8.25:-0.25)
3.20±1.54
(2.84:3.57)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4,0.0001,P5<0.0001,P6=0.02
Cylinder -4.78±1.80
-4.63 (-8.85:-1)
-2.73±1.16
-2.75 (-7.0:0.5)
-2.89±1.16
-3 (-6.75:0.25)
-3.0±1.38
-3.0 (-6.5:0.25)
1.78±1.35
(1.46:2.11)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.001,P5=0.008,P6=0.15
SE -8.85±3.50
-7.81 (-16:-3.25)
-4.29±2.26
-3.88 (-9.5:-0.13)
-4.58±2.31
-4.0 (-9.0:-0.5)
-4.76±2.54
-4.13 (-10.0:-0.5)
4.1±1.78
(3.67:4.52)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4<0.0001,P5<0.0001,P6=0.3
DEQ -6.46±3.02
-5.5 (-13:-1.5)
-2.94±2.07
-3 (-7.75:-0.25)
-3.13±2.11
-2.75 (-7.5:0)
-3.25±2.18
-2.88 (-8.25:-0.25)
3.21±1.55
(2.85:3.61)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4<0.0001,P5=0.0001,P6=0.7
K1 49.76±4.00
49.23 (43:64.7)
45.14±3.09
44.51 (39.45:52.09)
45.27±3.13
44.77 (39.33:52.6)
45.78±3.10
45.13 (40.16:53.43)
-3.98±3.30
(-4.76:-3.19)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.003,P5<0.0001,P6<0.0001
K2 54.90±4.26
55.26 (47.86:68.3)
49.16±3.34
49.06 (42:55.76)
49.41±3.35
49.27 (42.5:56.51)
49.77±3.40
49.8 (42.49:57.15)
-5.13±3.65
(-6.00:-4.26)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4<0.0001,P5<0.0001,P6<0.0001
Kaverageanterior 52.33±3.92
52.07 (46.59:66.5)
47.15±2.84
46.39 (42:53.80)
47.34±2.85
46.57 (42.03:54.17)
47.78±2.91
47.16 (42.16:54.45)
-4.55±3.20
(-5.32:-3.79)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4<0.0001,P5<0.0001,P6<0.0001
K max 58.55±4.92
58.69 (49.78:72.93)
53.19±4.02
52.34 (47.5:71.56)
53.42±4.02
52.65 (47.7:71.99)
83.92±4.11
53.30 (48.0:72.21)
-4.63±3.11
(-5.37:-3.89)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.002,P5<0.0001,P6<0.0001
Kaverageposterior -8.95±1.36
-8.1 (-11.3:-6.8)
-7.82±1.14
-7.4(-10.1:-6.5)
-7.89±1.22
-7.3 (-10.4:-6.4)
-7.93±1.26
-7.4 (-10.6:-6.4)
0.66±0.23
(0.48:0.76)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.12,P5=0.06,P6=0.07
Pachymetry 417.8±37.38
400 (370:517)
415.1±37.05
396.5 (368:510)
408.9±38.49
392 (350:506)
401.4±43.23
387.5 (334:491)
-16.34±19.87
(-21.08:-11.61)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4<0.0001,P5<0.0001,P6<0.0001

3.1. Visual, Refractive and Topographic Outcomes

3.1.1. Analysis of Total Studied Eyes (n=70)

Table 2 summarises the preoperative and postoperative data analysis of a total of 70 studied eyes. In general, at postoperative month 60, all studied eyes showed statistically significant improvements in mean UDVA, CDVA, sphere, cylinder, SE, K1, K2, Kaverages (i.e., Kaverageanterior and Kaverageposterior), Kmax, and pachymetry in comparison to their preoperative baseline values (all p<0.0001; p3 in Table 2). However, if we compared 3 postoperative time zones with each other (i.e., postoperative month 12 versus month 48 versus month 60), we simply exhibited that the postoperative month 12 had better outcomes than both postoperative months,48 and 60, in all parameters. In addition, the postoperative month 48 had better outcomes than postoperative month 60 in all para- meters. Eventually, both groups exhibited significant deterio- ration in previous parameters between their values at posto- perative months 12, 48, and 60 (p4, p5, and p6 in Table 2).

3.1.2. Analysis of Group A and B Studied Eyes

Tables 3 and 4 summarise the preoperative and postope- rative data analysis of group A and B studied eyes (n=37 and 33, respectively). At postoperative month 60, the studied eyes revealed statistically significant improvements in all mean parameters in case we compared every postoperative time zone separately (i.e., postoperative month 12, 48, or 60) with the preoperative baseline values (all p<0.0001; p3 in Tables 3 and 4). However, if we compared the 3 postoperative time zones with each other (i.e., postoperative month 12 versus month 48 versus month 60), we simply exhibited that the postoperative month 12 had better outcomes than both postoperative months, 48 and 60, in all parameters. In addition, the postoperative month 48 had better outcomes than postope- rative month 60 in all para- meters. Eventually, both groups exhibited significant deterioration in previous parame- ters between their values at postoperative months 12, 48, and 60 (p4, p5, and p6 in Tables 3 and 4).

Table 3. Visual, refractive, and topographic data analysis of group A (n=37).
Parameters Preoperative
Mean ± SD
Median (Range)
Postoperative
12th month
Mean ± SD
Median (Range)
Postoperative
48th month
Mean ± SD
Median (Range)
Postoperative
60th month
Mean ± SD
Median (Range)
Difference (post 60m-pre)
Mean ± SD
(95% CI)
P-value
UDVA 1.0±0.16
1.0 (0.7:1.3)
0.39±0.17
0.4 (0.1:0.8)
0.41±0.17
0.4 (0.1:0.7)
0.46±0.20
0.5 (0.2:1.0)
-0.54±0.18
(-0.59:-0.48)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=1.00,P5=0.24,P6=0.06
CDVA 0.37±0.17
0.4 (0:0.7)
0.15±0.10
0.1 (0:0.4)
0.13±0.09
0.1 (0:0.3)
0.14±0.09
0.1 (0:0.3)
-0.24±0.11
(-0.27:-0.20)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.02,P5=1.00,P6=1.00
Sphere -4.16±1.18
-4.25 (-6.75:-1.5)
-1.55±1.06
-1.5 (-3.5:0.25)
-1.72±1.07
-1.5 (-4:0)
-1.82±1.14
-1.5 (-4.5:-0.25)
2.34±1.04
(2.0:2.69)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.001,P5=0.06,P6=0.97
Cylinder -3.79±1.40
-4 (-6.25:-1)
-2.36±0.95
-2.5 (-3.75:0.5)
-2.53±0.98
-2.75 (-4:0.25)
-2.41±1.07
-2.5 (-4.5:0.25)
1.39±1.40
(0.92:1.85)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.03,P5=1.00,P6=0.38
SE -6.06±1.35
-6.13 (-8:-3.25)
-2.73±1.13
-2.75 (-5:-0.13)
-2.98±1.15
-3 (-5.38:-0.5)
-3.02±1.32
-3 (-6.13:-0.5)
3.04±1.15
(2.65:3.42)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.001,P5=0.25, P6=1.00
DEQ -4.16±1.18
-4.25 (-6.75:-1.5)
-1.56±1.10
-1.5 (-3.5:-0.25)
-1.71±1.08
-1.5 (-4:-0)
-1.81±1.14
-1.5 (-4.5:-0.25)
2.35±1.06
(1.79:2.56)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.006,P5=0.48, P6=0.12
K1 47.06±1.98
46.92 (43:51.28)
43.97±2.11
43.79 (40.29:49.24)
44.08±2.12
44.04 (40.44:49.19)
44.56±2.10
44.5 (40.36:49.38)
-2.50±1.81
(-3.10:-1.89)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.46,P5<0.0001,P6<0.0001
K2 51.64±2.35
51.36 (47.86:56.86)
47.86±2.70
47.19 (42:53.5)
48.07±2.70
47.54 (42.5:54)
48.35±2.66
47.79 (42.49:54.12)
-3.29±2.44
(-4.1:-2.47)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.008,P5<0.0001,P6<0.0001
Kaverageanterior 49.35±1.76
48.95 (46.59:53.01)
45.92±2.00
45.65 (42:50.90)
46.07±1.98
45.99 (42.03:50.81)
46.46±1.97
46.25 (42.16:50.82)
-2.89±1.69
(-3.46:-2.33)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.02,P5<0.0001,P6<0.0001
K max 56.34±4.76
55.45 (49.78:72.18)
52.77±4.52
51.74 (47.5:71.56)
52.89±4.50
51.66 (47.77:71.99)
53.18±4.58
52.05 (48:72.21)
-3.16±2.44
(-3.97:-2.34)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=1.00,P5=0.07,P6=0.02
Kaverageposterior -7.56±0.51
-7.5 (-9.1:-6.8)
-6.97±0.41
-6.9 (-8.2:-6.5)
-6.99±0.44
-6.9 (-8.3:-6.4)
-7±0.46
-6.8 (-8.4:-6.4)
0.56±0.18
(0.44:0.70)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.46,P5=0.18,P6=1.00
Pachymetry 440.5±38.07
445 (372:517)
437.8±37.45
437 (370:510)
431.86±39.26
431 (365:506)
425.6±41.2
427 (339:486)
-14.86±14.77
(-19.79:-9.94)
<0.0001
P1=0.11, P2<0.0001, P3<0.0001,P4<0.0001,P5<0.0001,P6=0.01
Table 4. Visual, refractive, and topographic data analysis of group B (n=33).
Parameters Preoperative
Mean ± SD
Median (Range)
Postoperative
12th month
Mean ± SD
Median (Range)
Postoperative
48th month
Mean ± SD
Median (Range)
Postoperative
60th month
Mean ± SD
Median (Range)
Difference (post-60m-pre)
Mean ± SD
(95% CI)
P-value
UDVA 1.45±0.19
1.5 (1:1.7)
0.61±0.18
0.6 (0.3:1.0)
0.68±0.20
0.6 (0.4:1.1)
0.81±0.26
0.8 (0.3:1.4)
-0.64±0.20
(-0.71:-0.57)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.02,P5<0.0001,P6<0.0001
CDVA 0.56±0.15
0.5 (0.3:0.9)
0.24±0.11
0.2 (0.1:0.7)
0.23±0.11
0.2 (0.1:0.6)
0.25±0.12
0.3 (0.1:0.6)
-0.31±0.11
(-0.35:-0.27)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=1.00,P5=1.00,P6=0.16
Sphere -9.04±2.27
-9.25 (-13.25:-4)
-4.46±1.80
-4.75 (-7.75:-0.5)
-4.71±1.84
-5 (-7.5:-0.75)
-4.87±1.91
-5 (-8.25:-1)
4.17±1.45
(3.65:4.68)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.03,P5=0.049,P6=0.33
Cylinder -5.90±1.54
-5.75 (-8.85:-3)
-3.15±1.25
-3 (-7:-0.25)
-3.30±1.23
-3 (-6.75:-1)
-3.67±1.40
-3.5 (-6.5:-0.5)
2.23±1.15
(1.82:2.64)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.36,P5=0.03,P6=0.03
SE -11.99±2.29
-12.5 (-16:-6.75)
-6.04±1.89
-6.25 (-9.5:-1.75)
-6.36±1.95
-6.5 (-9.0:-1.75)
-6.70±2.12
-6.88 (-10:-2.38)
5.28±1.62
(4.71:5.85)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.02,P5=0.02,P6=0.06
DEQ -9.04±2.26
-9.25 (-13.25:-4)
-4.48±1.80
-4.75 (-7.75:-0.5)
-4.71±1.84
-5 (-7.5:-0.75)
-4.87±1.91
-5 (-8.25:-1)
4.17±1.45
(3.49:5.06)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.04,P5=0.03,P6=0.09
K1 52.78±3.51
52.25 (47.57:64.7)
46.45±3.49
46.78 (39.45:52.09)
46.61±3.54
46.88 (39.33:52.6)
47.15±3.48
46.7 (40.16:53.43)
-5.63±3.80
(-6.98:-4.29)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.11,P5<0.0001,P6<0.0001
K2 58.56±2.63
58.23 (55.2:68.3)
50.62±3.43
51.24 (44.19:55.76)
50.91±3.40
51.43 (44.65:56.51)
51.37±3.47
52.14 (44.13:57.15)
-7.19±3.69
(-8.50:-5.88)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.01,P5<0.0001,P6<0.0001
Kaverageanterior 55.67±2.80
55.19 (53.06:66.5)
48.53±3.03
49.03 (42.15:53.80)
48.76±3.03
49.21 (42.48:54.17)
49.26±3.10
49.54 (42.96:54.45)
-6.41±3.49
(-7.65:-5.18)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.003,P5<0.0001,P6<0.0001
K max 61.03±3.83
60.15 (52.78:72.93)
53.66±3.39
53.2 (47.58:60.72)
54.02±3.38
53.81 (47.7:60.97)
54.75±3.40
54.26 (48.04:61.27)
-6.28±2.97
(-7.33:-5.22)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.004,P5<0.0001,P6<0.0001
Kaverageposterior -9.74±1.05
-9.9 (-11.3:-8)
-8.78±0.92
-9 (-10.1:-7.2)
-8.91±0.99
-9.1 (-10.4:-7)
-8.98±1.03
-9.1 (-10.6:-7)
0.76±0.24
(0.52:0.98)
<0.0001
P1<0.0001, P2<0.0001, P3<0.0001,P4=0.03,P5=0.008,P6=0.01
Pachymetry 392.4±11.00
394 (370:433)
389.58±10.71
389 (368:431)
383.2±12.98
384 (350:426)
374.4±26.3
374 (334:491)
-18±24.51
(-26.69:-9.31)
<0.0001
P1=0.001, P2<0.0001, P3=0.001,P4<0.0001,P5=0.004,P6=0.11
3.1.2.1. Between-group Comparisons

Table 5 summarises the postoperative mean differences between both groups at postoperative month 60. We recorded between-group significant differences in all of the mean refractive, visual and topographic parameters at baseline, except for pachymetry (p=0.06; Table 5). Furthermore, we discovered that group B had greater postoperative improve- ments with higher mean UDVA, CDVA, sphere, cylinder (p=0.04, 0.02, p<0.0001, 0.01, respectively; Table 5), SE, K1, K2, Kaverageanterior, Kmax, and Kaverageposterior than in group A (all p<0.0001, Table 5).

3.1.2.2. Between-subgroup Comparisons

Table 6 shows the preoperative and postoperative between-subgroup comparisons based on the postoperative stability status at postoperative month 60. Eventually, the stability, improvement, and progression subgroups included 35, 16, and 19 eyes, respectively, at 60m. Nevertheless, here, we present only the preoperative and postoperative differences at 60m among the three subgroups (i.e., pall in Table 6). We observed no statistically significant differences regarding mean values of all parameters except UDVA, cylinder, Kaverageposterior, and pachymetry. We observed a higher mean UDVA and Kaverageposterior differences value of -0.75±0.16 logMAR and 0.83±0.24 D, respectively, in the I-subgroup than other subgroups (pall=0.0001 and 0.003 respectively). In addition, the I-subgroup revealed a higher mean cylinder difference value of 2.29±0.96 D than other subgroups (pall=0.03). However, we observed a higher mean pachymetry difference value of -34.74±7.32 µm in the P-subgroup than other subgroups (pall=0.0001).

3.1.3. Progression-subgroup Outcomes (n=19)

Table 7 summarises the postoperative differences at postoperative months 12, 48, and 60. The diagnosis of KCP was confirmed only when Kmax deteriorated more than 1 D (Kmax>1 D). All values at postoperative month 12 were considered as the baseline for calculating any postoperative changes, whether improvement or progression. At postope- rative 48m, the Kmax differences values (postoperative 48m-postoperative 12m values) in all 70 studied eyes ranged from -1.89 to 0.87 D, and no case revealed Kmax>1 D; thus, postoperative KCP was excluded at this time-point of the follow-up. Unfortunately, at postoperative 60m, 19 out of these 70 studied eyes revealed definite progression as Kmax differences values (postoperative 60m-postoperative 12m values) ranged from 1.13 to 4.42 D (i.e., Kmax>1 D, Table 7), and we finally documented postoperative KCP in these 19 eyes (1,3,5 and 10 eyes in grades 1, 2, 3 and 4 KC respectively) identified as P-subgroup. Eventually, the P-subgroup included 19 eyes with documented PR-KCP at 60m, 4 eyes from group A (11% progression rate in group A), and 15 eyes from group B (45% progression rate in group B).

Table 5. Comparative analysis of the visual, refractive, and topographic outcomes in group A versus group B.
Variable Group A
Mean ± SD
Median (range)
Group B
Mean ± SD
Median (range)
P-value
UDVA:
Preoperative
Post 60ms-Preoperative
1.0±0.16
1 (0.7:1.3)
-0.54±0.18
-0.5 (-0.8:-0.2)
1.45±0.19
1.5 (1:1.7)
-0.64±0.20
-0.6 (-1.0:-0.3)
<0.0001
0.04
CDVA:
Preoperative
Post 60ms-Preoperative
0.37±0.17
0.4 (0:0.7)
-0.24±0.11
-0.3 (-0.4:0)
0.56±0.15
0.5 (0.3:0.9)
-0.31±0.11
-0.3 (-0.5:-0.1)
<0.0001
0.02
Sphere:
Preoperative
Post 60ms-Preoperative
-4.16±1.18
-4.25 (-6.75:-1.5)
2.34±1.04
2.25 (0.75:4.5)
-9.04±2.27
-9.25 (-13.25:-4)
4.17±1.45
4 (2:9)
<0.0001
<0.0001
Refractive Cylinder:
Preoperative
Post 60ms-Preoperative
-3.79±1.40
-4 (-6.25:-1.0)
1.39±1.40
1.25 (-2.5:4.25)
-5.90±1.5
-5.75 (-8.85:-3)
2.23±1.16
2.25 (0:4.5)
<0.0001
0.01
SE:
Preoperative
Post 60ms-Preoperative
-6.06±1.35
-6.13 (-8.0:-3.25)
3.04±1.16
3.13 (1.0:5.13)
-11.99±2.29
-12.5 (-16:-6.75)
5.28±1.62
5.13 (2.63:10.13)
<0.0001
<0.0001
DEQ:
Preoperative
Post 60ms-Preoperative
-4.16±1.18
-4.25 (-6.75:-1.5)
-1.81±1.14
-1.5 (-4.5:-0.25)
-9.04±2.26
-9.25 (-13.25:-4)
-4.87±1.91
-5 (-8.25:-1)
<0.0001
<0.0001
K1:
Preoperative
Post 60ms-Preoperative
47.06±1.98
46.92 (43:51.28)
-2.50±1.81
-2.75 (-7.63:1.41)
52.78±3.51
52.25 (47.57:64.7)
-5.63±3.80
-4.63 (-15.25:0.32)
<0.0001
<0.0001
K2:
Preoperative
Post 60ms-Preoperative
51.64±2.35
51.36 (47.86:56.86)
-3.29±2.44
-3.17 (-11:1.81)
58.56±2.63
58.23 (55.2:68.3)
-7.19±3.70
-6.1 (-14.06:-1.96)
<0.0001
<0.0001
Kaverageanterior:
Preoperative
Post 60ms-Preoperative
49.35±1.76
48.95 (46.59:53.01)
-2.89±1.69
-2.51 (-6.77:0.79)
55.67±2.80
55.19 (53.06:66.5)
-6.41±3.48
-5.97 (-14.21:-1.68)
<0.0001
<0.0001
K max:
Preoperative
Post 60ms-Preoperative
56.34±4.76
55.45 (49.78:72.18)
-3.16±2.44
-3.18 (-12.09:0.61)
61.03±3.83
60.15 (52.78:72.93)
-6.28±2.97
-6.21 (-13.51:-0.33)
<0.0001
<0.0001
Kaverageposterior:
Preoperative
Post 60ms-Preoperative
-7.56±0.51
-7.5 (-9.1:-6.8)
0.56±0.18
0.50 (0.30:1.00)
-9.74±1.05
-9.9 (-11.3:-8)
0.76±0.24
0.70 (0.40:1.2)
<0.0001
<0.0001
Pachymetry:
Preoperative
Post 60ms-Preoperative
440.5±38.07
445 (372:517)
-14.86±14.77
-10 (-76:-4)
392.4±11.01
394 (370:433)
-18±24.51
-13 (-51:91)
<0.0001
0.06
Table 6. Comparative analysis of the visual, refractive, and topographic outcomes between the 3 postoperative subgroups.
Variables
Mean ± SD
Median (range)
S-subgroup
N=35 eyes
I-subgroup
N=16 eyes
P-subgroup
N=19 eyes
P all P1 P2 P3
UDVA Preoperative 1.11±0.27
1 (0.7:1.7)
1.21±0.25
1.15 (0.8:1.7)
1.4±0.26
1.5 (1.0:1.7)
0.002 0.21 0.001 0.04
Post 60ms 0.54±0.22
0.5 (0.2:1.0)
0.45±0.19
0.45 (0.2:0.9)
0.93±0.22
0.9 (0.5:1.4)
0.0001 0.15 0.0001 0.0001
Post 60ms-Preop -0.57±0.17
-0.6 (-0.9:-0.3)
-0.75±0.16
-0.8 (-1:-0.4)
-0.47±-0.16
-0.5 (-0.9:-0.2)
0.0001 0.001 0.048 0.0001
CVDA Preoperative 0.42±0.18
0.4 (0:0.7)
0.44±0.17
0.45 (0.2:0.9)
0.55±0.20
0.06 (0.1:0.9)
0.05 0.94 0.02 0.06
Post 60ms 0.16±0.10
0.2 (0:0.3)
0.13±0.12
0.1 (0:0.5)
0.29±0.10
0.3 (0.1:0.6)
0.0001 0.17 0.0001 0.0001
Post 60ms-Preop -0.26±0.11
-0.3 (-0.5:0)
-0.31±0.08
-0.3 (-0.4:-0.2)
-0.26±0.15
-0.3 (-0.5:0)
0.25 0.09 0.97 0.25
Sphere Preoperative -5.35±2.41
-4.75 (-11.5:-1.5)
-6.14±3.07
-4.88 (-11.5:-2.5)
-8.78±2.82
-9 (-13.25:-3.5)
0.001 0.59 0.0002 0.02
Post 60ms -2.61±1.89
-2 (-7.25:-0.25)
-2.59±1.70
-2 (-6:-0.25)
-5±2.14
-5 (-8.25:-1.25)
0.0001 0.68 0.0003 0.003
Post 6ms-Preop 2.73±1.28
2.75 (0.75:5.25)
3.54±1.63
2.75 (1.75:7.0)
3.78±1.71
3.75 (0.75:0.9)
0.05 0.15 0.02 0.44
Ref Cyl Preoperative -4.58±1.77
-4.5 (-8.25:-1)
-4.49±2.11
-4 (-8.85:-1.5)
-5.41±1.51
-5.5 (-8.25:-2.25)
0.14 0.56 0.10 0.08
Post 60ms -2.7±1.10
-3 (-5.5:0.25)
-2.20±1.14
-2 (-6:-0.5)
-4.20±1.08
-4.25 (-6.5:-2.25)
0.0001 0.04 0.0001 0.0001
Post 60ms-Preop 1.86±1.55
1.5 (-2.5:4.25)
2.29±0.96
2.13 (1:4.5)
1.21±1.06
1 (-1.25:2.75)
0.03 0.26 0.09 0.007
SE Preoperative -7.64±2.84
-7.25 (-14.25:-3.25)
-8.39±3.67
-6.69 (-15.25:-4.25)
-11.48±3.20
-12.5 (-16:-4.63)
0.001 0.69 0.0003 0.02
Post 60ms -3.97±2.01
-3.25 (-8.88:-0.75)
-3.70±2.08
-3 (-7.5:-0.5)
-7.10±2.33
-7.75 (-10:-2.38)
0.0001 0.55 0.0001 0.0003
Post 60ms-Preop 3.67±1.58
3.5 (1.13:7.13)
4.69±1.80
4.06 (2.38:8.75)
4.38±2.00
4.5 (1:10.13)
0.16 0.08 0.19 0.86
K1 Preoperative 49.01±3.80
48.65 (43.75:64.7)
49.05±3.40
48.59 (43:54.63)
51.73±4.35
51.69 (44:59.75)
0.04 1.00 0.049 0.14
Post 60ms 45.36±2.47
45 (41:52.8)
45.70±3.26
45.88 (40.16:50.56)
46.63±3.93
45.19 (41.12:53.43)
0.36 1.00 0.47 1.00
Post 60ms-Preop -3.65±3.00
-3.06 (-11.9:0.05)
-3.35±2.79
-3.97 (-8.09:1.41)
-5.1±4.05
-4.25 (-15.25:-0.65)
0.38 0.94 0.21 0.22
K2 Preoperative 53.93±4.17
53.42 (48.11:68.3)
54.27±4.14
54.25 (49.1:61.18)
57.23±3.81
58.11 (47.86:63.12)
0.02 1.00 0.02 0.11
Post 60ms 49.35±3.12
48.15 (44.79:56.1)
49.15±3.88
50.05 (42.49:55.17)
51.08±3.33
52 (46.11:57.15)
0.15 1.00 0.23 0.29
Post 60ms-Preop -4.58±3.73
-3.76 (-14.06:1.81)
-5.12±2.98
-4.94 (-12.37:0.17)
-6.15±3.93
-4.94 (-13.17:-0.32)
0.20 0.24 0.11 0.53
K averageanterior Preoperative 51.47±3.78
50.90 (46.81:66.5)
51.66±3.50
52.01 (46.59:57.91)
54.48±3.86
55.19 (46.88:60.16)
0.02 1.00 0.02 0.09
Post 60ms 47.36±2.53
46.84 (42.96:54.45)
47.43±3.16
47.15 (42.16:51.87)
48.85±3.23
47.71 (44.3:54.20)
0.17 1.00 0.22 0.45
Post 60ms-Preop -4.11±3.03
-3.02 (-12.29:-0.56)
-4.23±2.63
-4.35 (-9.06:0.79)
-5.63±3.80
-4.64 (-14.21:-1.25)
0.26 0.45 0.12 0.37
K max Preoperative 58.10±5.39
57.35 (50.26:72.93)
58.06±5.22
57.83 (49.78:69.25)
59.79±3.59
59.78 (52.95:67.17)
0.44 1.00 0.70 0.91
Post 60ms 53.54±4.63
4.63 (48.04:72.21)
53.19±3.82
52.31 (48:60.11)
55.24±3.09
54.37 (50.86:61.21)
0.26 1.00 0.45 0.44
Post 60ms-Preop -4.56±3.44
-4.13 (-13.51:0.61)
-4.87±3.27
-3.57 (-12.27:-1.18)
-4.56±2.38
-5 (-8.33:-0.1)
0.90 0.75 0.66 0.97
K averageposterior Preoperative -8.2±1.2
-7.7 (-10.9:-6.8)
-8.21±1.22
-7.85 (-11.2:-6.9)
-9.63±1.24
-9.7 (-11.3:-7.6)
0.009 1.00 0.03 0.02
Post 60ms -7.6±1.08
-7.1 (-10.2:-6.5)
-7.38±1.06
-7.05 (-10.1:-6.4)
-9.01±1.13
-9.1 (-10.6:-7.1)
0.002 1.00 0.01 0.008
Post 60ms-Preop 0.60±0.21
0.6 (0.3:1.2)
0.83±0.24
0.8 (0.5:1.2)
0.62±0.18
0.6 (0.4:1.1)
0.003 0.03 0.45 0.005
Pachynetry Preoperative 422.7±39.91
415 (370:494)
418.1±36.60
401 (374:494)
408.6±33.09
398 (374:517)
0.42 1.00 0.58 1.00
Post 60ms 411.7±42.63
405 (339:485)
401.8±40.83
392 (364:491)
373.8±35.18
361 (334:482)
0.004 1.00 0.005 0.02
Post 60ms-Preop -10.94±11.65
-9 (-76:-4)
-16.31±28.98
-8.5 (-53:91)
-34.74±7.32
-33 (-51:-26)
0.0001 0.66 0.0001 0.0001
Table 7. Visual, refractive, and topographic postoperative differences of P-subgroup (n=19).
Parameters Postoperative 12m - Preoperative
Mean ± SD
Median (Range)
Postoperative 48m
- Postop 12m
Mean ± SD
Median (Range)
Postoperative 60m
- Postop 48m
Mean ± SD
Median (Range)
Postoperative 60m
- Postop 12m
Mean ± SD
Median (Range)
Difference
(post 60m-pre)
Mean ± SD
Median (Range)
P-value
UDVA -0.88±0.16
-0.9 (-1.3:-0.7)
0.11±0.03
0.1 (0.1:0.2)
0.31±0.12
0.3 (0.1:0.6)
0.42±0.12
0.4 (0.2:0.7)
-0.47±0.16
-0.5 (-0.9:-0.2)
<0.0001
P1=0.0001, P2=0.0001, P3=0.002
CDVA -0.36±0.13
-0.4 (-0.6:-0.1)
0.01±0.05
0 (0:0.2)
0.09±0.05
0.1 (0:0.2)
0.11±0.07
0.1 (0:0.3)
-0.26±0.15
-0.3 (-0.5:0)
<0.0001
P1=0.0001, P2=0.0001, P3=0.0001
Sphere 4.70±1.71
4.75 (2.25:9.5)
-0.20±0.20
-0.25 (-0.5:0.25)
-0.72±0.43
-0.75 (-1.5:-0.25)
-0.92±0.46
-0.75 (-1.75:-0.5)
3.78±1.71
3.75 (0.75:9)
<0.0001
P1=0.0001, P2=0.0001, P3=0.59
Cylinder 2.52±1.03
2.5 (0.25:4)
-0.43±0.45
-0.5 (-1:0.5)
-0.88±0.50
-0.75 (-1.75:0)
-1.32±0.67
-1.5 (-2.5:-0.25)
1.21±1.06
1 (-1.25:2.75)
<0.0001
P1=0.0001, P2=0.0001, P3=0.01
SE 5.9±1.93
5.88 (2.88:10.75)
-0.41±0.29
-0.50 (-1:0)
-1.16±0.56
-1.13 (-2.25:-0.5)
-1.58±0.57
-1.5 (-2.63:-0.63)
4.38±2.00
4.5 (1:10.13)
<0.0001
P1=0.0001, P2=0.0001, P3=0.19
K1 -6.12±4.00
-5.48 (-16.22:-1.7)
0.53±0.28
0.45 (0.18:1.04)
0.50±0.29
0.58 (-0.05:0.83)
1.02±0.20
0.99 (0.71:1.53)
-5.1±4.05
-4.25 (-15.25:-0.65)
<0.0001
P1=0.0001, P2=0.0001, P3=0.02
K2 -7.49±4.00
-6.22 (-14.57:-1.62)
0.59±0.43
0.75 (-0.95:0.94)
0.76±0.44
0.65 (0.04:1.72)
1.34±0.39
1.36 (0.6:2.49)
-6.15±3.93
-4.94 (-13.17:-0.32)
<0.0001
P1=0.0001, P2=0.0001, P3=0.84
Kaverageanterior -6.81±3.78
-5.87 (-14.99:-2.45)
0.56±0.19
0.52 (0.05:0.95)
0.63±0.24
0.63 (0.1:1.06)
1.18±0.21
1.2 (0.79:1.63)
-5.63±3.80
-4.64 (-14.21:-1.25)
<0.0001
P1=0.0001, P2=0.0001, P3=0.003
K max -6.58±2.68
-9.36 (-12.65:-1.53)
0.71±0.09
0.70 (0.46:0.87)
1.31±1.10
0.76 (0.46:3.77)
2.02±1.13
1.45 (1.13:4.42)
-4.56±2.38
-5 (-8.33:-0.1)
<0.0001
P1=0.0001, P2=0.0001, P3=0.10
Kaverageposterior 1.1±0.26
0.9 (0.6:1.5)
-0.27±0.09
-0.3 (-0.4:-0.1)
-0.11±0.07
-0.1 (-0.2:0)
-0.38±0.13
-0.4 (-0.6:-0.1)
0.62±0.18
0.6 (0.4:1.1)
<0.0001
P1=0.0001, P2=0.0001, P3=0.003
Pachymetry -4.26±3.12
-3 (-11:1)
-6.58±5.81
-5 (-23:-2)
-23.58±10.05
-23 (-42:-4)
-30.47±7.22
-29 (-48:-19)
-34.74±7.32
-33 (-51:-26)
<0.0001
P1=0.002, P2=0.0001, P3=0.001

Table 8 summarizes the postoperative differences between groups A and B regarding outcomes of the eyes in the P-subgroup. At postoperative month 60, we recorded that the B group revealed statistically significant differences with greater deterioration in its P-subgroup eyes than in group A in all parameters except CDVA and pachymetry (p=0.13 and 0.19 respectively, Table 8).

3.1.4. Statistical Outcomes of Suggested New Values to Document PR-KCP

All eyes in P-subgroup showed a mean deterioration of 0.71 D in Kmax at 48m. Furthermore, all eyes revealed a loss of one line or more of UDVA with a mean deterioration of 0.18 logMAR at 48m at a time when Kmax deterioration ranged from 0.46 D to 0.87 D, i.e., Kmax did not exceed 1 D (Table 7). Therefore, we did not document KCP at 48m. In addition, all eyes revealed deterioration in a mean sphere, cylinder, SE, K1, K2, Kaverageanterior, and Kaverageposterior of -0.20, -0.43, -0.41, 0.39, 0.59, 0.49, and -0.27 D, respectively, at 48m (Table 7). Moreover, CCT showed a mean loss of 6.58 µm (1.6% of baseline postoperative thickness) at 48 months (Table 7).

Table 8. Comparative analysis of the visual, refractive, and topographic outcomes of the keratoconus progression cases in P-subgroups in group A versus group B.
Variable
Mean ± SD
Median (range)
P-subgroup in group A
n=4 eyes (21.05%)
P-subgroup in group B
n=15 eyes (78.95%)
P-value
UDVA:
Preoperative
Post 60m-Preoperative
1.08±0.10
1.05 (1.0:1.2)
-0.33±0.15
-0.3 (-0.5:-0.2)
1.49±0.21
1.5 (1.0:1.7)
-0.51±0.14
-0.5 (-0.9:-0.3)
0.002
0.08
CDVA:
Preoperative
Post 60m-Preoperative
0.38±0.25
0.35 (0.1:0.7)
-0.15±0.17
-0.1 (-0.4:0)
0.6±0.16
0.6 (0.3:0.9)
-0.29±0.13
-0.3 (-0.5:-0.1)
0.09
0.13
Sphere:
Preoperative
Post 60m-Preoperative
-4.44±0.72
-4.5 (-5.25:-3.5)
1.88±0.85
2 (0.75:2.75)
-9.93±1.81
-10.25 (-13.25:-7.25)
4.28±1.52
3.75 (2.75:9)
0.003
0.003
Refractive Cylinder:
Preoperative
Post 60m-Preoperative
-3.63±1.25
-3.5 (-5.25:-2.25)
0.06±0.90
0.38 (-1.25:0.75)
-5.88±1.19
-5.5 (-8.25:-4.25)
1.51±0.89
1.5 (0:2.75)
0.01
0.02
SE
Preoperative
Post 60m-Preoperative
-6.25±1.18
-6.63 (-7.13:-4.63)
1.91±0.89
1.75 (1.0:3.13)
-12.88±1.72
-12.88 (-16:-9.75)
5.04±1.67
4.63 (3.25:10.13)
<0.0001
0.003
K1:
Preoperative
Post 60m-Preoperative
45.37±1.00
45.59 (44:46.28)
-2.21±1.14
-2.43 (-3.31:-0.65)
53.42±3.09
53.25 (48.89:59.75)
-5.87±4.21
-4.63 (-15.25:-1.2)
0.0001
0.09
K2:
Preoperative
Post 60m-Preoperative
51.40±3.06
51.21 (47.86:55.34)
-2.29±1.57
-2.45 (-3.74:-0.32)
58.78±2.09
59.13 (55.7:63.12)
-7.18±3.73
-6.1 (-13.17:-2.33)
<0.0001
0.01
Kaverageanterior:
Preoperative
Post 60m-Preoperative
48.38±1.16
48.50 (46.88:49.67)
-2.25±0.74
-2.36 (-3.01:-1.25)
56.10±2.33
56.21 (53.1:60.16)
-6.53±3.79
-5.97 (-14.21:-1.77)
<0.0001
0.01
K max:
Preoperative
Post 60m-Preoperative
55.56±2.72
55.15 (52.95:58.99)
-1.97±2.19
-1.39 (-5:-0.1)
60.92±2.92
60.42 (54.4:67.17)
-5.25±1.95
-5.2 (-8.33:-1.91)
0.004
0.02
Kaverageposterior
Preoperative
Post 60m-Preoperative
-8±0.34
-8 (-8.4:-7.6)
0.5±0.08
0.5 (0.4:0.6)
-10.6±0.99
-10.4 (-11.3:-8.5)
0.65±0.19
0.6(0.4:1.1)
<0.0001
0.008
Pachymetry:
Preoperative
Post 60m-Preoperative
458.8±39.57
422.5 (433:517)
-30.5±3.70
-30 (-35:-27)
395.2±12.69
394 (374:433)
-35.87±7.70
-35 (-51:-26)
<0.0001
0.19
Table 9. Comparison between prior known parameter values for keratoconus progression and the new suggested values for post-ring implantation keratoconus progression (PR-KCP).
Parameters The known published progression values in the literature The new suggested values for PR-KCP
Kmax ≥1 D [38, 40, 41] ≥0.75 D
Kaverage anterior ≥0.75 D ≥0.50 D
Kaverageposterior - ≥0.25 D
Pachymetry ≥2% reduction in central corneal thickness [41] ≥1.5% reduction in thinnest corneal point (CCT)
Cylinder ≥1 D [40, 41] ≥0.50 D
SE ≥0.50 D [40, 41] ≥0.40 D
UDVA loss of one line or more [27] ≥0.10 logMAR (loss of one line or more)
CDVA loss of one line or more [27, 48] ≥0.10 logMAR (loss of one line or more)

Table 9 shows the comparison between known prior parameters' values for keratoconus progression and the suggested new values for post-ring implantation keratoconus progression (PR-KCP) depending on our statistical data analysis of the postoperative differences in-between the 3 follow-up time-points at postoperative months 12, 48, and 60 which are recorded in Table 7.

In summary, At postoperative month 60, group-B exhibited significantly higher values of all mean uncorrected distance visual acuity (UDVA), corrected distance visual acuity (CDVA), sphere/cylinder/spherical equivalent/defocus equival- ent(DEQ), and K1/K2/Kaverages/Kmax parameters compared to that of group A. However, group-A exhibited better stability of postoperative improvements. Keratoconus progression (KCP) was greater in group-B (45.5%) than group-A (10.8%)

3.2. Complications

Table 10 summarises the recorded postoperative complications at postoperative month 60 and how we managed these complications. Fig. (1) shows one eye with Keraring segments' migration, while Fig. (2) shows the tunnel vascularization, opacification, and scarring of one eye with Keraring segments' migration.

4. DISCUSSION

This study included 70 eyes 70 keratoconus patients that underwent TCXL combined with Keraring segment implantation. All eyes completed at least 5 years of follow-up to be included in this study. We exhibited a high rate of complications in 20 eyes at the end of this study. Nineteen eyes with KCP, two of these 19 eyes were also complicated with additional segments' migration. Meanwhile, the twentieth eye was complicated with vascularization, opacification of the tunnel, and also segments' migration.

Table 10. Late postoperative complications in the two study groups at postoperative month 60.
Complications Group A
N=37 eyes
Group B
N=33 eyes
Management Fate
KC progression rate 4
(11%)
15
(45%)
After the end of the study:
- 5 eyes in group A (CTT>400 µm) were scheduled for accelerated epithelium-off CXL retreatment.
- 10 eyes in group B (CTT 350-400 µm with Kmax<2 D) were scheduled for accelerated epithelium-off CXL retreatment using hypoosmolar riboflavin solution.
- 4 eyes in group B (grade 4 KC, CTT<350 µm with Kmax>3 D) were scheduled for deep anterior lamellar keratoplasty (DALK).
The 19 eyes retreated as scheduled after the end of the study. The patients were requested to continue regular follow-up visits every 6 months.
Segments' migration 1
(2.7%)
1
(3%)
- Both eyes with Segments' migration were also documented with postoperative KCP and were actually part of the P-subgroup
- One eye in group A exhibited visual and topographic deterioration. We explanted these segments and retreated this eye with repeat epithelium off CXL.
- The other eye in group B suffered from visual distortion, haloes, and glare with patient discomfort. Finally, we explanted these segments, and the patient was scheduled for DALK.
Both eyes received their scheduled treatments after the end of the study. The patients were requested to continue regular follow-up visits every 6 months.
Vascularization, opacification and scarring of the tunnel associated with segments' migration 1
(2.7%)
- The patient data shows visual and topographic stability despite segments’ migration.
- We decided to avoid surgical interference as long as this stability continues.
Follow-up every 6 months.
Fig. (1). Keraring segments’ migration in one eye in group B.

Fig. (2). Keraring segments' migration with the tunnel vascularization, opacification, and scarring in one eye in group A.

Our study demonstrated that high-grade keratoconus (grades 3 and 4 AK) yielded better postoperative outcomes in all parameters than the low-grade keratoconus (grades 1 and 2 AK). However, the high-grade keratoconus exhibited a higher rate of postoperative progression than the low-grade keratoconus (45% versus 11% respectively, P<0.0001). In particular, grades 1, 2, 3, and 4 revealed 1, 3, 5, and 10 cases of postoperative progression, respectively. Therefore, we recommend avoiding implantation of ICRS in grade 4 AK keratoconus as it has a high tendency to continue its progression postoperatively. Alternatively, if the surgeon's decision was to implant ICRS, we recommend avoiding TCXL and perform epithelium off CXL considering the use of hypotonic riboflavin solution in high-grade keratoconus.

Our findings suggest that the values regularly used to document preoperative KCP were not ideal to document postoperative KCP, especially in eyes implanted with ICRS. We could possibly have earlier documentation of PR-KCP with earlier surgical interference if the parameters were diagnostic at lower postoperative values than preoperative ones. It was discovered that all eyes that exhibited deterioration of Kmax≥0.71 D finally revealed more deterioration to exceed 1D within a few months later. Therefore, we suggested that if Kmax increases ≥0.75 D, then postoperative KCP should be documented at this level, and another retreatment option should be performed.

Furthermore, we also suggest that PR-KCP should be documented by one of two methods. The first method to document PR-KCP is based on one sole parameter only, which is either Kmax if deteriorated ≥0.75 D. The second method to document PR-KCP is based on the existence of two or more of the following parameters: Kmax≥0.50 D, Kaverageanterior≥0.50 D, Kaverageposterior ≥0.25 D, CTT ≥ 1.5% thickness reduction and UDVA or CDVA ≥0.10 logMAR (loss of one or more lines on acuity chart).

Nevertheless, at 48m, we failed to expect early PR-KCP as we depended on prior known parameters and criteria published in the literature to document progression. Unfortunately, none of the values of the current study had achieved the already known prior criteria to document KCP at 48m. Therefore, an early chance was missed to diagnose and retreat KCP. In short, UDVA showed early significant changes in P-subgroup eyes at 48m when the other known parameters did not achieve the known values that were used to document KCP. In other words, patients presented with a postoperative deterioration of UDVA should be scheduled for close follow-up on a 6-monthly basis to avoid missing early postoperative KC progression.

Alio et al. [27] reported the 5-year outcomes of their patients in a retrospective study. They determined their own criteria of success, including UDVA or CDVA gain of one or more lines, while their failure criteria included UDVA or CDVA loss of one or more lines. They concluded ICRS that revealed good results in advanced KC. However, they believed that early KC with good UDVA is a contraindication to ICRS implantation to avoid losing lines of visual acuity. They also recommended avoiding ICRS implantation in progressive KC cases and shifting to other treatment options. Their outcomes were close to ours as we also demonstrated better outcomes in high-grade than in low-grade KC. Furthermore, we demonstrated that UDVA was an early sensitive parameter to document KCP. The main difference between both studies was simply that they implanted Keraring segments in stable and progressive KC cases while we implanted Keraring segments in progressive KC cases only. In addition, we performed TCXL for all our studied eyes, which was not the case in their studied eyes.

As regards the efficacy of combined treatment with TCXL, although postoperative stability is achieved in the first few years, we demonstrated that nineteen eyes (27%) showed definite KCP at the fifth postoperative year. The only explanation of these results is the use of TCXL in our study, which maintains stability for a shorter period of time than standard Cxl.

On the other hand, in a previous study, we (Iqbal et al.) [8] documented no KCP cases for complete postoperative five years following SCXL. This significant difference in the postoperative rate of KCP in both studies proves that SCXL is more effective in the stabilization of ectatic cornea and halting KCP.

Several studies reported different rates of KCP following ICRS implantation. Saleem et al. [31] documented a 14% postoperative rate of KCP. They also reported that 2% of cases revealed spontaneous ring exposure. Our team, in previous research [37], demonstrated a 6% progression rate and 3% segments' migration rate in pediatric patients in postoperative month 18. In a couple of studies of Mounir et al. [48, 49], they reported lower segments' migration rate of 1.5% but documented no cases of postoperative progression in one study; however, their second study revealed 2% segments' extrusion rate but also documented no cases with postoperative progression. On the contrary, to our outcomes, Wild et al. [50] concluded the outcomes of implanting Keraring segments in 70 eyes. They concluded that their implantation outcomes were better in mild KC (mean K<48 D) than in severe KC (mean K>55 D). In their series eyes, they reported that 4% of cases underwent segments explantation because of corneal vascularization; however, they reported no KCP cases in 12 months follow-up period. Nevertheless, 3% of our studied eyes underwent segment explantation, while 27% of the studied eyes were documented with KCP in 60 months follow-up period.

Moreover, Elsaftawy et al. [51] compared Keraring implantation alone versus implantation of Keraring combined with TCXL in a short-term 6 months study. They finally concluded that the addition of TCXL was superior and more advantageous in postoperative improvements and halting KCP. On the contrary, we concluded that TCXL is not effective in halting KCP on long-term follow-up

An important question remains. Why did we choose TCXL instead of SXCL in this present study? The answer is simply related to the time when we operated the studied eyes. Actually, Keratoconus disease is being treated in our localities in Egypt for more than 15 years, and we now have reasonable experience in this field [8, 18, 29, 30, 35]. We started the cross-linking procedures in 2009 using SCXL alone that showed the best CXL outcomes ever in halting KCP. Unfortunately, TCXL was our main CXL procedure for almost 3 years (years 2012 to 2015) because we thought that TCXL was an equivalent procedure to SCXL in efficacy, thus avoiding the potential SCXL postoperative complications. . We acknowledge that we were wrong, and TCXL is less efficient than SCXL. The studied eyes were operated during this time-period shift and discovered that the main disadvantage of TCXL was its weak ability to halt KCP for long-term postoperative periods despite its apparent good outcomes in the early short-term postoperative period. Therefore, the SCXL treatment was again used for patients as the main CXL procedure, especially in young and pediatric patients [18].

Another important question remains. Was KCP the cause of the segments' migration in the current study? Or did the segments' migration accelerate KCP? In other words, Can the cone protrusion and displacement cause migration of the segments? Is the reverse correct? We are not sure if the postoperative progression was responsible for the segments’ migration in this study. Nevertheless, It was believed that the nature of preoperative KCP is different from postoperative one. It was observed that ICRS implantation somehow affects postoperative KCP by either slowing, masking, or accelerating it; however, the underlying mechanism of action of ICRS in the active postoperative progression is not fully understood. Several studies [27, 52, 53] demonstrated that ICRS actually induced corneal remodelling. Alio et al. [27] explained this action by the reduction in the optical aberrations due to improvement of optical properties following ICRS implantation. In addition, Ly et al. [52] used the in vivo confocal microscopy in their study and concluded that ICRSs caused the migration of the fibroblasts with lipid deposition in the extracellular matrix due to their mechanical stresses, thus inducing corneal remodelling. Moreover, Samimi et al. [53] reported that ICRS was associated with keratocyte apoptosis that might be reversible after removal of the implants. The previously reported findings also suggest fibrosis of the tunnel during the wound healing process that could partially induce corneal remodelling. However, we believe that ICRS can help either to stabilize the ectatic cornea or to accelerate postoperative KCP depending on two main factors. The first factor is associated with CXL, while the second is the accurate site and depth of ICRS implantation. TCXL had been found to be effective in halting keratoconus by many studies. This technique overcomes the limitations of a conventional protocol with higher safety and acceptable efficacy [54-56].

On the other hand, Flecha-Lescún et al. [57] theoretically hypothesized that implantation of the segments in the posterior corneal stroma could halt KCP while their implantation in the anterior corneal stroma could properly accelerate KCP. On the contrary, to this theory, Abd Elaziz et al. [58] evaluated the implantation of 355° Keraring segment in the treatment of advanced KC with central cones. They concluded that this type of segment was effective and revealed marked visual and refractive improvements. However, they stated that the actual mean 61% tunnel depth of segment insertion was superficial to their primary intension, 80% tunnel depth. Their findings oppose the theory introduced by Flecha-Lescún et al. [57], as discussed earlier.

The main limitation of our study was the unavailability of patients’ topographic data for the second and third postoperative years. Another limitation was the small number of the studied eyes. Unfortunately, both Belin [59] ABCD grading system 2016 and the new manufacturer’s Keraring nomogram version 2018 were not available when studied eyes operated before 2016. Therefore, an older Amsler-Krumeich grading system and the manufacturer’s Keraring nomogram version 2009 were used. In addition, several studies [44-47], [60-64] recommended the use of the recent Belin ABCD progression display and the BAD for diagnosis of KC progression. We actually did not test the BAD tool as it is unfortunately incorporated only in Pentacam HR (Oculus Inc., Wetzlar, Germany) while we used other types of topographers in our study.

CONCLUSION

We believe that TCXL should not be the first choice for the treatment of progressive KC. In addition, we think that ICRS implantation should not be a basic choice for the treatment of progressive KC until the condition becomes stable for a long period. We also recommend that the indication of ICRS implantation in KC is better to be limited in cases with contact lens intolerability. Furthermore, we believe that ICRS could be considered as supporting implants if the segments’ size and thickness were properly chosen and appropriately implanted. On the other hand, we think that ICRS can act as traumatising implants if not properly selected or perfectly implanted. In the two previous conditions, ICRS could help to stabilize or accelerate KCP; thus the ideal ICRS implants do not exist. Moreover, we think that grade 4 KC should be considered as a contraindication to ICRS implantation as we documented 52.6% of KCP eyes (10 out of 19 eyes) in this grade 4 alone in comparison to other grades. We now believe that the prior known values of the parameters determining preoperative KCP are actually underestimating the real postoperative progression. Therefore, we recommend lowering these values for documenting postoperative KCP to start an early second intervention to halt such progression.

ETHICS APPROVAL AND CONSENT TO PARTICIPATE

This retrospective cohort study is approved by the Institutional Review Board of the Sohag Faculty of Medicine, Sohag University, Egypt. under ethical approval no. (IRB-8-8/4/2019).

HUMAN AND ANIMAL RIGHTS

No Animals were used in this research. All human research procedures followed were in accordance with the ethical standards of the committee responsible for human experimentation (institutional and national), and with the Helsinki Declaration of 1975, as revised in 2013.

CONSENT FOR PUBLICATION

Informed consent was taken from all the patients when they were enrolled.

AVAILABILITY OF DATA AND MATERIALS

The patients’ data used to support the findings of this study are available from the corresponding author [A.M] upon request.

FUNDING

None.

CONFLICT OF INTEREST

The authors declare no conflict of interest, financial or otherwise.

ACKNOWLEDGEMENTS

We would like to thank Dr. Mona Abo-Ali, Mr. Hamza Mohammed, Mr. Seif Mohammed, and Ms. Lina Mohammed for the assistance in this research. We are grateful for Prof. Fouad Metry Yosef, the expert statistician who performed all statistical analyses. We are also grateful for the help and support of the EPK Group.

REFERENCES

[1] Rabinowitz YS. Keratoconus. Surv Ophthalmol 1998; 42(4): 297-319.
[2] Solomon A. Corneal complications of vernal keratoconjunctivitis. Curr Opin Allergy Clin Immunol 2015; 15(5): 489-94.
[3] Shetty R, Sureka S, Kusumgar P, Sethu S, Sainani K. Erratum: Allergen specific exposure associated with high immunoglobulin E and eye rubbing predisposes to progression of keratoconus. Indian J Ophthalmol 2017; 65(7): 642-3.
[4] Lee R, El-Massry A, El-Massry Y, Randleman JB. Bilateral, asymmetric keratoconus induced by thyrotoxicosis with long-term stability after corneal cross-linking. J Refract Surg 2018; 34(5): 354-6.
[5] El-Massry A, Doheim MF, Iqbal M, et al. Association between keratoconus and thyroid gland dysfunction: A cross-sectional case-control study. J Refract Surg 2020; 36(4): 253-7.
[6] Bilgihan K, Hondur A, Sul S, Ozturk S. Pregnancy-induced progression of keratoconus. Cornea 2011; 30(9): 991-4.
[7] Raiskup F, Theuring A, Pillunat LE, Spoerl E. Corneal collagen crosslinking with riboflavin and ultraviolet-A light in progressive keratoconus: ten-year results. J Cataract Refract Surg 2015; 41(1): 41-6.
[8] Iqbal M, Elmassry A, Badawi AE, Gharieb HM, Said OM. Visual and refractive long-term outcomes following standard cross-linking in progressive keratoconus management. Clin Ophthalmol 2019; 13: 2477-88.
[9] Wollensak G, Spoerl E, Seiler T. Riboflavin/ultraviolet-a-induced collagen crosslinking for the treatment of keratoconus. Am J Ophthalmol 2003; 135(5): 620-7.
[10] Lang PZ, Hafezi NL, Khandelwal SS, Torres-Netto EA, Hafezi F, Randleman JB. Comparative functional outcomes after corneal crosslinking using standard, accelerated, and accelerated with higher total fluence protocols. Cornea 2019; 38(4): 433-41.
[11] Woo JH, Iyer JV, Lim L, et al. Conventional versus accelerated collagen cross-linking for keratoconus: A comparison of visual, refractive, topographic and biomechanical outcomes. Open Ophthalmol J 2017; 11: 262-72.
[12] Ziaei M, Vellara H, Gokul A, Patel D, McGhee CNJ. Prospective 2-year study of accelerated pulsed transepithelial corneal crosslinking outcomes for Keratoconus. Eye (Lond) 2019; 33(12): 1897-903.
[13] Elmassry A, Said Ahmed OI, Abdalla MF, Gaballah K. Ten years experience of corneal collagen cross-linking: An observational study of 6120 cases. Eur J Ophthalmol 2020.1120672120928921 [published online ahead of print, 2020 Jun 4].
[14] Galvis V, Tello A, Carreño NI, et al. Corneal cross-linking (with a partial deepithelization) in keratoconus with five years of follow-up. Ophthalmol Eye Dis 2016; 8: 17-21.
[15] Rechichi M, Daya S, Scorcia V, Meduri A, Scorcia G. Epithelial-disruption collagen crosslinking for keratoconus: One-year results. J Cataract Refract Surg 2013; 39(8): 1171-8.
[16] Madeira C, Vasques A, Beato J, et al. Transepithelial accelerated versus conventional corneal collagen crosslinking in patients with keratoconus: A comparative study. Clin Ophthalmol 2019; 13: 445-52.
[17] Choi M, Kim J, Kim EK, Seo KY, Kim TI. Comparison of the conventional Dresden protocol and accelerated protocol with higher ultraviolet intensity in corneal collagen cross-linking for keratoconus. Cornea 2017; 36(5): 523-9.
[18] Iqbal M, Elmassry A, Saad H, et al. Standard cross-linking protocol versus accelerated and transepithelial cross-linking protocols for treatment of paediatric keratoconus: A 2-year comparative study. Acta Ophthalmol 2020; 98(3): e352-62.
[19] Wen D, Li Q, Song B, et al. Comparison of standard versus accelerated corneal collagen cross-linking for keratoconus: A meta-analysis. Invest Ophthalmol Vis Sci 2018; 59(10): 3920-31.
[20] Rush SW, Rush RB. Epithelium-off versus transepithelial corneal collagen crosslinking for progressive corneal ectasia: A randomised and controlled trial. Br J Ophthalmol 2017; 101(4): 503-8.
[21] Mazzotta C, Wollensak G, Raiskup F, Pandolfi AM, Spoerl E. The meaning of the demarcation line after riboflavin-UVA corneal collagen crosslinking. Expert Rev Ophthalmol 2019; 14(2): 115-31.
[22] Yousef HS. A comparative study between epithelium-on and epithelium-off collagen cross-linking with riboflavin and ultraviolet radiation in the treatment of early keratoconus. J Egypt Ophthalmol Soc 2016; 109: 109-16.
[23] Hafez MI. Comparison of epithelium-off and transepithelial corneal collagen cross-linking for treatment of keratoconus. J Egypt Ophthalmol Soc 2014; 107: 181-6.
[24] Ahmed Saleem MH. Combined cross-linking with femtosecond laser myoring implantation versus combined cross-linking with femtosecond laser keraring implantation in the treatment of keratoconus. J Egypt Ophthalmol Soc 2015; 108: 140-7.
[25] Heikal MA, Abdelshafy M, Soliman TT, Hamed AM. Refractive and visual outcomes after Keraring intrastromal corneal ring segment implantation for keratoconus assisted by femtosecond laser at 6 months follow-up. Clin Ophthalmol 2016; 11: 81-6.
[26] Fariselli C, Vega-Estrada A, Arnalich-Montiel F, Alio JL. Artificial neural network to guide intracorneal ring segments implantation for keratoconus treatment: a pilot study. Eye Vis (Lond) 2020; 7: 20.
[27] Alio JL, Vega-Estrada A, Esperanza S, Barraquer RI, Teus MA, Murta J. Intrastromal corneal ring segments: how successful is the surgical treatment of keratoconus? Middle East Afr J Ophthalmol 2014; 21(1): 3-9.
[28] Randleman JB, Santhiago MR, Kymionis GD, Hafezi F. Corneal cross-linking (CXL): standardizing terminology and protocol nomenclature. J Refract Surg 2017; 33(11): 727-9.
[29] Iqbal M, Elmassry A, Tawfik A, et al. Evaluation of the effectiveness of cross-linking combined with photorefractive keratectomy for treatment of keratoconus. Cornea 2018; 37(9): 1143-50.
[30] Abou Samra W, Mokbel T, Elwan M, et al. Two-stage procedure in the management of selected cases of keratoconus: clear lens extraction with aspherical IOL implantation followed by WFG-PRK. Int J Ophthalmol 2018; 11(11): 1761-7.
[31] Saleem MIH, Ibrahim Elzembely HA, AboZaid MA, et al. Three-year outcomes of cross-linking PLUS (Combined cross-linking with femtosecond laser intracorneal ring segments implantation) for management of keratoconus. J Ophthalmol 2018; 20186907573
[32] Hafez MI. Refractive meridional corneal collagen cross-linking: A new modified technique for treatment of astigmatism. Delta J Ophthalmol 2015; 16: 5-9.
[33] Bor’i A. Simultaneous versus sequential photorefractive keratectomy and cross-linking for the management of early keratoconus. Delta J Ophthalmol 2016; 17: 123-7.
[34] Imbornoni LM, McGhee CNJ, Belin MW. Evolution of keratoconus: From diagnosis to therapeutics. Klin Monbl Augenheilkd 2018 Jun; 235(6): 680-8.
[35] Gharaibeh AM, Muhsen SM, AbuKhader IB, Ababneh OH, Abu-Ameerh MA, Albdour MD. KeraRing intrastromal corneal ring segments for correction of keratoconus. Cornea 2012; 31(2): 115-20.
[36] Iqbal M, Elmassry A, Tawfik A, et al. Analysis of the outcomes of combined cross-linking with intracorneal ring segment implantation for the treatment of pediatric keratoconus. Curr Eye Res 2019; 44(2): 125-34.
[37] Rocha G, Silva LNP, Chaves LFOB, Bertino P, Torquetti L, de Sousa LB. Intracorneal ring segments implantation outcomes using two different manufacturers’ nomograms for keratoconus surgery. J Refract Surg 2019; 35(10): 673-83.
[38] Epstein RL, Chiu YL, Epstein GL. Pentacam HR criteria for curvature change in keratoconus and postoperative LASIK ectasia. J Refract Surg 2012; 28(12): 890-4.
[39] Sykakis E, Karim R, Evans JR, et al. Corneal collagen cross-linking for treating keratoconus. Cochrane Database Syst Rev 2015; (3): CD010621
[40] Wittig-Silva C, Chan E, Islam FM, Wu T, Whiting M, Snibson GR. A randomized, controlled trial of corneal collagen cross-linking in progressive keratoconus: three-year results. Ophthalmology 2014; 121(4): 812-21.
[41] Chatzis N, Hafezi F. Progression of keratoconus and efficacy of pediatric [corrected] corneal collagen cross-linking in children and adolescents. J Refract Surg 2012; 28(11): 753-8.
[42] Suzuki M, Amano S, Honda N, Usui T, Yamagami S, Oshika T. Longitudinal changes in corneal irregular astigmatism and visual acuity in eyes with keratoconus. Jpn J Ophthalmol 2007; 51(4): 265-9.
[43] Gomes JA, Tan D, Rapuano CJ, et al. Global consensus on keratoconus and ectatic diseases. Cornea 2015; 34(4): 359-69.
[44] Belin M, Meyer J, Duncan J, Gelman R, Borgstrom M, Ambrósio R. Assessing progression of keratoconus and cross-linking efficacy: The belin ABCD progression display. Int J Keratoconus Ectatic Corneal Dis 2017; 6(1): 1-10.
[45] Duncan JK, Belin MW, Borgstrom M. Assessing progression of keratoconus: Novel tomographic determinants. Eye Vis (Lond) 2016; 3: 6.
[46] Ambrósio R Jr, Caiado AL, Guerra FP, et al. Novel pachymetric parameters based on corneal tomography for diagnosing keratoconus. J Refract Surg 2011; 27(10): 753-8.
[47] Lopes BT, Ramos IC, Faria-Correia F, et al. Correlation of topometric and tomographic indices with visual acuity in patients with keratoconus. J Kerat Ect Cor Dis 2012; 1(3): 167-72.
[48] Mounir A, Radwan G, Farouk MM, Mostafa EM. Femtosecond-assisted intracorneal ring segment complications in keratoconus: From novelty to expertise. Clin Ophthalmol 2018; 12: 957-64.
[49] Mounir A, Farouk MM, Abdellah MM, Mohamed Mostafa E. Extrusion of Ffmtosecond laser-implanted intrastromal corneal ring segments in keratoconic eyes: Prevalence, Risk factors, and Clinical outcomes. J Ophthalmol 2020; 20208704219
[50] Wilde CL, Naylor SG, Varga Z, Morrell A, Ball JL. Keraring implantation using the Zeiss Visumax femtosecond laser in the management of patients with keratoconus. Eye (Lond) 2017; 31(6): 916-23.
[51] Elsaftawy HS, Ahmed MH, Saif MY, Mousa R. Sequential intracorneal ring segment implantation and corneal transepithelial collagen cross-linking in keratoconus. Cornea 2015; 34(11): 1420-6.
[52] Ly LT, McCulley JP, Verity SM, Cavanagh HD, Bowman RW, Petroll WM. Evaluation of intrastromal lipid deposits after intacs implantation using in vivo confocal microscopy. Eye Contact Lens 2006; 32(4): 211-5.
[53] Samimi S, Leger F, Touboul D, Colin J. Histopathological findings after intracorneal ring segment implantation in keratoconic human corneas. J Cataract Refract Surg 2007; 33(2): 247-53.
[54] Konstantopoulos A, Mehta JS. Conventional versus accelerated collagen cross-linking for keratoconus. Eye Contact Lens 2015; 41(2): 65-71.
[55] O’Brart DPS. Corneal collagen crosslinking for corneal ectasias: A review. Eur J Ophthalmol 2017; 27(3): 253-69.
[56] Soeters N, Wisse RP, Godefrooij DA, Imhof SM, Tahzib NG. Transepithelial versus epithelium-off corneal cross-linking for the treatment of progressive keratoconus: A randomized controlled trial. Am J Ophthalmol 2015; 159(5): 821-8.e3.
[57] Flecha-Lescún J, Calvo B, Zurita J, Ariza-Gracia MÁ. Template-based methodology for the simulation of intracorneal segment ring implantation in human corneas. Biomech Model Mechanobiol 2018; 17(4): 923-38.
[58] Abd Elaziz MS, El Saebay Sarhan AR, Ibrahim AM, Elshafy Haggag HA. Anterior segment changes after femtosecond laser-assisted implantation of a 355-degree intrastromal corneal ring segment in advanced keratoconus. Cornea 2018; 37(11): 1438-43.
[59] Belin MW, Duncan JK. Keratoconus: The ABCD Grading System. Klin Monatsbl Augenheilkd 2016; 233(6): 701-7.
[60] Motlagh MN, Moshirfar M, Murri MS, et al. Pentacam® corneal tomography for screening of refractive surgery candidates: A review of the literature, part I. Med Hypothesis Discov Innov Ophthalmol 2019; 8(3): 177-203.
[61] Orucoglu F, Toker E. Comparative analysis of anterior segment parameters in normal and keratoconus eyes generated by scheimpflug tomography. J Ophthalmol 2015; 2015925414
[62] Mounir A. An Easy Guide To Pentacam Corneal Tomographgy. 2020. Available at: https://www.innovationinfobooks.com/ebook details/an-easy-guide-to-pentacam-corneal-tomography [Accessed 11 August 2020].
[63] Luz A, Lopes B, Hallahan KM, et al. Enhanced combined tomography and biomechanics data for distinguishing forme fruste keratoconus. J Refract Surg 2016; 32(7): 479-94.
[64] Ambrósio R Jr, Correia FF, Lopes B, et al. Corneal biomechanics in ectatic diseases: Refractive surgery implications. Open Ophthalmol J 2017; 11: 176-93.
